List of Parameters
Parameters
1-101
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the simulation mode for digital inputs.
Dependency: The setpoint for the input signals is specified using p0796.
Refer to: p0796
Note: This parameter is not saved when data is backed up (p0971).
DI: Digital input
AI: Analog Input
T: Terminal
Description: Sets the setpoint for the input signals in the digital input simulation mode.
Dependency: The simulation of a digital input is selected using p0795.
Refer to: p0795
Note: This parameter is not saved when data is backed up (p0971).
DI: Digital input
AI: Analog Input
T: Terminal
p0795 CU digital inputs simulation mode / CU DI simulation
Access level: 3 Calculated: - Data type: Unsigned32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) Simulation Terminal eval. -
01 DI 1 (T. 6) Simulation Terminal eval. -
02 DI 2 (T. 7) Simulation Terminal eval. -
03 DI 3 (T. 8) Simulation Terminal eval. -
04 DI 4 (T. 16) Simulation Terminal eval. -
05 DI 5 (T. 17) Simulation Terminal eval. -
11 DI 11 (T. 3, 4) AI 0 Simulation Terminal eval. -
12 DI 12 (T.10, 11) AI 1 Simulation Terminal eval. -
p0796 CU digital inputs simulation mode setpoint / CU DI simul setp
Access level: 3 Calculated: - Data type: Unsigned32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
04 DI 4 (T. 16) High Low -
05 DI 5 (T. 17) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
12 DI 12 (T. 10, 11) AI 1 High Low -
