Siemens CU230P-2 DP - p20274 LVM 0 run sequence; LVM 0 RunSeq; p20275 CI: LVM 1 input X; LVM 1 input X; p20276 LVM 1 interval average value M; LVM 1 avg value M; p20277 LVM 1 interval limit L; LVM 1 limit L

List of Parameters
Parameters
1-389
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run sequence of instance LVM 0 within the run-time group set in p20273.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantity X of instance LVM 1 of the double-sided limiter.
Description: Setting parameter for the interval average M of instance LVM 1 of the double-sided limiter.
Description: Setting parameter for the interval limit L of instance LVM 1 of the double-sided limiter.
Description: Setting parameter for hysteresis HY of instance LVM 1 of the double-sided limiter.
Description: Display parameter of instance LVM 1 of the double-sided limiter that input quantity X was at least once X > M + L
and X is >= M + L - HY.
Description: Display parameter of instance LVM 1 of the double-sided limiter that the input quantity X lies within the interval.
p20274 LVM 0 run sequence / LVM 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 7999 720
p20275 CI: LVM 1 input X / LVM 1 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
p20276 LVM 1 interval average value M / LVM 1 avg value M
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
p20277 LVM 1 interval limit L / LVM 1 limit L
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
p20278 LVM 1 hyst HY / LVM 1 hyst HY
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
r20279 BO: LVM 1 input quantity above interval QU / LVM 1 X above QU
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r20280 BO: LVM 1 input quantity within interval QM / LVM 1 X within QM
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
