Siemens CU230P-2 DP - p1781[0...n] Motor model Rs adaptation integral time; MotMod Rs Tn; r1782[0...n] Motor model Rs adaptation corrective value; MotMod Rs corr; p1783[0...n] Motor model Rs adaptation Kp; MotMod Rs Kp; p1785[0...n] Motor model Lh adaptation Kp; MotMod Lh Kp

List of Parameters
Parameters
1-209
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the integral time for the Rs adaptation of the motor model for an induction motor (ASM).
Description: Displays the corrective value for the Rs adaptation of the motor model for an induction motor (ASM).
Dependency: Refer to: p0826, p1780
Note: The display of the inactive data sets is only updated when changing over the data set.
Description: Sets the proportional gain for the Rs adaptation of the motor model for an induction motor (ASM).
Description: Sets the proportional gain for the Lh adaptation of the motor model for an induction motor (ASM).
Description: Sets the integral time for the Lh adaptation of the motor model for an induction motor (ASM).
Description: Displays the corrective value for the Lh adaptation of the motor model for an induction motor (ASM).
Dependency: Refer to: p0826, p1780
Note: The adaptation result is reset if the magnetizing inductance of the induction motor is changed (p0360, r0382). This
also happens when changing over the data set if a different motor is not being used (p0826).
The display of the inactive data sets is only updated when changing over the data set.
Description: Displays the power-on stator frequency for the Rs adaptation for the induction motor (ASM).
p1781[0...n] Motor model Rs adaptation integral time / MotMod Rs Tn
Access level: 4 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
10 [ms] 10000 [ms] 100 [ms]
r1782[0...n] Motor model Rs adaptation corrective value / MotMod Rs corr
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [Ohm] Scaling: - Data set: DDS, p0180
p1783[0...n] Motor model Rs adaptation Kp / MotMod Rs Kp
Access level: 4 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.000 1.000 0.100
p1785[0...n] Motor model Lh adaptation Kp / MotMod Lh Kp
Access level: 4 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.000 1.000 0.100
p1786[0...n] Motor model Lh adaptation integral time / MotMod Lh Tn
Access level: 4 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
10 [ms] 10000 [ms] 100 [ms]
r1787[0...n] Motor model Lh adaptation corrective value / MotMod Lh corr
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [mH] Scaling: - Data set: DDS, p0180
r1789 Motor model Rs adaptation switch-in frequency / MotMod Rs f_on
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [Hz] Scaling: - Data set: -
