List of Parameters
Parameters
1-343
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the ramp-up and ramp-down time for the maximum and minimum limit (p11191, p11192) of the free technol-
ogy controller 1.
Dependency: Refer to: p11191, p11192
Note: The ramp-up/ramp-down times are referred to 100%.
Description: Display and connector output for the output signal of the free technology controller 1.
Description: Sets the signal source for the maximum limit of the free technology controller 1.
Dependency: Refer to: p11191
Description: Sets the signal source for the minimum limit of the free technology controller 1.
Dependency: Refer to: p11192
Description: Sets the signal source for the limit offset of the free technology controller 1.
p11193 Free tec_ctrl 1 limit ramp-up/ramp-down time / Ftec1 lim r-u/r-dn
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.00 [s] 100.00 [s] 1.00 [s]
r11194 CO: Free tec_ctrl 1 output signal / Ftec1 out_sig
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
p11197 CI: Free tec_ctrl 1 limit maximum signal source / Ftec1 lim max s_s
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 11191[0]
p11198 CI: Free tec_ctrl 1 limit minimum signal source / Ftec1 lim min s_s
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 11192[0]
p11199 CI: Free tec_ctrl 1 limit offset signal source / Ftec1 lim offs
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
