Siemens CU230P-2 DP - r0038 Power factor smoothed; Cos phi smooth; r0039 Energy consumption; Energy consumption; p0040 Reset energy consumption display; Energy usage reset; p0045 Smoothing time constant, display values; T_smth display

Parameters
List of Parameters
1-22
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the smoothed actual power factor.
Note: Smoothing time constant = 300 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
Significance for the motor: Motor power factor
Significance for the infeed: Power factor at the connection point (p3470, p3471)
Description: Displays the electrical energy used since the last reset.
Dependency: Refer to: p0040
Description: Setting to reset the energy consumption display (r0039).
Procedure: Set p0040 = 0 --> 1.
The display is reset and the parameter is automatically set to zero.
Dependency: Refer to: r0039
Description: Sets the smoothing time constant for the following display values:
r0063[1], r0068[1], r0080[1], r0082[1].
r0038 Power factor smoothed / Cos phi smooth
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: - Data set: -
r0039 Energy consumption / Energy consumption
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [kWh] Scaling: - Data set: -
p0040 Reset energy consumption display / Energy usage reset
Access level: 3 Calculated: - Data type: Unsigned8
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0 1 0
p0045 Smoothing time constant, display values / T_smth display
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.00 [ms] 1000.00 [ms] 4.00 [ms]
