List of Parameters
Parameters
1-309
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the output of timer 3.
The activated weekday (p8430) and the switch-on/off time (p8431/p8432) switch these two binector outputs.
Dependency: Refer to: p8430, p8431, p8432
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
Description: Displays the ACX file saved in the appropriate directory in the non-volatile memory.
Dependency: Refer to: p1000
Note: For a value = 9999999, the following applies: The read operation is still running.
Description: Displays the ACX file saved in the appropriate directory in the non-volatile memory.
Dependency: Refer to: p1500
Note: For a value = 9999999, the following applies: The read operation is still running.
Description: Indicates which macro is presently being run in the drive object.
Dependency: Refer to: p0700, p1000, p1500, r8572, r8573
r8433.0...1 BO: RTC DTC3 output / RTC DTC3 output
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Timer on Yes No -
01 Timer ON negated No Yes -
r8572[0...39] Macro Connector Inputs (CI) for speed setpoints / Macro CI n_set
Access level: 4 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r8573[0...39] Macro Connector Inputs (CI) for torque setpoints / Macro CI M_set
Access level: 4 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r8585 Actual macro running / Actual macro
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
