Siemens CU230P-2 DP - p20157 PCL 1 run sequence; PCL 1 RunSeq; p20158 BI: PDE 0 input pulse I; PDE 0 inp_pulse I; p20159 PDE 0 pulse delay time in ms; PDE 0 t_del ms; r20160 BO: PDE 0 output Q; PDE 0 output Q

Parameters
List of Parameters
1-370
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run sequence of instance PCL 1 within the run-time group set in p20156.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance PDE 0 of the closing delay device.
Description: Setting parameter for pulse delay time T in milliseconds of instance PDE 0 of the closing delay device.
Description: Display parameter for output pulse Q of instance PDE 0 of the closing delay device.
Description: Setting parameter for the run-time group in which instance PDE 0 of the closing delay device is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance PDE 0 within the run-time group set in p20161.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance PDE 1 of the closing delay device.
p20157 PCL 1 run sequence / PCL 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 410
p20158 BI: PDE 0 input pulse I / PDE 0 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
p20159 PDE 0 pulse delay time in ms / PDE 0 t_del ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 60000.00 0.00
r20160 BO: PDE 0 output Q / PDE 0 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20161 PDE 0 run-time group / PDE 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20162 PDE 0 run sequence / PDE 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 430
p20163 BI: PDE 1 input pulse I / PDE 1 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
