Siemens CU230P-2 DP - p0761[0...3] CU analog inputs wire breakage monitoring response threshold; CU WireBrkThresh; p0762[0...3] CU analog inputs wire breakage monitoring delay time; CU wire brk t_del; p0771[0...1] CI: CU analog outputs signal source; CU AO sig_source; r0772[0...1] CU analog outputs, output value currently referred; CU AO outp_val

List of Parameters
Parameters
1-97
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the response threshold for the wire breakage monitoring of the analog inputs.
The unit for the parameter value depends on the set analog input type.
Index: [0] = AI0 (T. 3/4)
[1] = AI1 (T. 10/11)
[2] = AI2 (T. 50/51)
[3] = AI3 (T. 52/53)
Dependency: For the following analog input type, the wire breakage monitoring is active:
p0756[0...1] = 1 (unipolar voltage input monitored (+2 V ... +10 V)), unit [V]
p0756[0...2] = 3 (unipolar current input monitored (+4 mA ... +20 mA)), unit [mA]
p0756[3]: Wire breakage monitoring is not supported for this analog input.
Refer to: p0756
Note: When p0761 = 0, wire breakage monitoring is not carried out.
Description: Sets the delay time for the wire breakage monitoring of the analog inputs.
Index: [0] = AI0 (T. 3/4)
[1] = AI1 (T. 10/11)
[2] = AI2 (T. 50/51)
[3] = AI3 (T. 52/53)
Description: Sets the signal source for the analog outputs.
Index: [0] = AO0 (T 12/13)
[1] = AO1 (T 26/27)
Note: AO: Analog Output
T: Terminal
Description: Displays the actual referred output value of the analog outputs.
Index: [0] = AO0 (T 12/13)
[1] = AO1 (T 26/27)
Note: AO: Analog Output
T: Terminal
p0761[0...3] CU analog inputs wire breakage monitoring response threshold / CU WireBrkThresh
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.00 20.00 2.00
p0762[0...3] CU analog inputs wire breakage monitoring delay time / CU wire brk t_del
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0 [ms] 1000 [ms] 100 [ms]
p0771[0...1] CI: CU analog outputs signal source / CU AO sig_source
Access level: 2 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
r0772[0...1] CU analog outputs, output value currently referred / CU AO outp_val
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: - Data set: -
