List of Parameters
Parameters
1-393
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run-time group in which the instance ADD 2 of the adder is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance ADD 2 within the run-time group set in p20310.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantities X0 and X1 of instance NCM 0 of the numeric comparator.
Index: [0] = Input X0
[1] = Input X1
Description: Display parameter for binary quantity QU of instance NCM 0 of the numeric comparator.
QU is only set if X0 > X1.
Description: Display parameter for binary quantity QE of instance NCM 0 of the numeric comparator.
QE is only set if X0 = X1.
Description: Display parameter for binary quantity QL of instance NCM 0 of the numeric comparator.
QL is only set if X0 < X1.
p20310 ADD 2 run-time group / ADD 2 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20311 ADD 2 run sequence / ADD 2 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 800
p20312[0...1] CI: NCM 0 inputs / NCM 0 inputs
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
r20313 BO: NCM 0 output QU / NCM 0 output QU
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r20314 BO: NCM 0 output QE / NCM 0 output QE
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r20315 BO: NCM 0 output QL / NCM 0 output QL
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
