List of Parameters
Parameters
1-253
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Trigger signal for the selected faults and alarms
Dependency: If one of the faults or alarms selected in p2128[n] occurs, then the particular bit of this binector output is set.
Refer to: p2128
Note: CO: r2129 = 0 --> None of the selected messages has occurred.
CO: r2129 > 0 --> At least one of the selected messages has occurred.
Description: Displays the system runtime in days when the fault occurred.
Dependency: Refer to: r0945, r0947, r0948, r0949, r2109, r2133, r2136, p8401
Notice: The time comprises r2130 (days) and r0948 (milliseconds).
The value displayed in p2130 refers to 01.01.1970.
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
Description: Displays the code of the oldest active fault.
Note: 0: No fault present.
Description: Displays the code of the last alarm that occurred.
Note: 0: No alarm present.
Description: Displays additional information about the fault that occurred for float values.
Dependency: Refer to: r0945, r0947, r0948, r0949, r2109, r2130, r2136
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
r2129.0...15 CO/BO: Trigger word for faults and alarms / Trigger word
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Trigger signal p2128[0] On Off -
01 Trigger signal p2128[1] On Off -
02 Trigger signal p2128[2] On Off -
03 Trigger signal p2128[3] On Off -
04 Trigger signal p2128[4] On Off -
05 Trigger signal p2128[5] On Off -
06 Trigger signal p2128[6] On Off -
07 Trigger signal p2128[7] On Off -
08 Trigger signal p2128[8] On Off -
09 Trigger signal p2128[9] On Off -
10 Trigger signal p2128[10] On Off -
11 Trigger signal p2128[11] On Off -
12 Trigger signal p2128[12] On Off -
13 Trigger signal p2128[13] On Off -
14 Trigger signal p2128[14] On Off -
15 Trigger signal p2128[15] On Off -
r2130[0...63] Fault time received in days / t_fault recv days
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2131 CO: Actual fault code / Actual fault code
Access level: 2 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2132 CO: Actual alarm code / Actual alarm code
Access level: 2 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2133[0...63] Fault value for float values / Fault val float
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: - Data set: -
