Siemens CU230P-2 DP - p0758[0...3] CU analog inputs characteristic value y1; CU AI char y1; p0759[0...3] CU analog inputs characteristic value x2; CU AI char x2; p0760[0...3] CU analog inputs characteristic value y2; CU AI char y2

Parameters
List of Parameters
1-96
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the normalization characteristic for the analog inputs.
The normalization characteristic for the analog inputs is defined using two points.
This parameter specifies the y coordinate (percentage) of the 1st value pair of the characteristic.
Index: [0] = AI0 (T. 3/4)
[1] = AI1 (T. 10/11)
[2] = AI2 (T. 50/51)
[3] = AI3 (T. 52/53)
Note: The parameters for the characteristic do not have a limiting effect.
Description: Sets the normalization characteristic for the analog inputs.
The normalization characteristic for the analog inputs is defined using two points.
This parameter specifies the x coordinate (V, mA, °C) of the 2nd value pair of the characteristic.
Index: [0] = AI0 (T. 3/4)
[1] = AI1 (T. 10/11)
[2] = AI2 (T. 50/51)
[3] = AI3 (T. 52/53)
Note: The parameters for the characteristic do not have a limiting effect.
Description: Sets the normalization characteristic for the analog inputs.
The normalization characteristic for the analog inputs is defined using two points.
This parameter specifies the y coordinate (percentage) of the 2nd value pair of the characteristic.
Index: [0] = AI0 (T. 3/4)
[1] = AI1 (T. 10/11)
[2] = AI2 (T. 50/51)
[3] = AI3 (T. 52/53)
Note: The parameters for the characteristic do not have a limiting effect.
p0758[0...3] CU analog inputs characteristic value y1 / CU AI char y1
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
-1000.00 [%] 1000.00 [%] 0.00 [%]
p0759[0...3] CU analog inputs characteristic value x2 / CU AI char x2
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
-50.000 160.000 10.000
p0760[0...3] CU analog inputs characteristic value y2 / CU AI char y2
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
-1000.00 [%] 1000.00 [%] 100.00 [%]
