List of Parameters
Parameters
1-307
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the switch-on time of the timer in hours and minutes.
BO: r8423 = 1 signal:
The condition for the set weekday (p8420) and switch-on time has been fulfilled.
Index: [0] = Hour (0 ... 23)
[1] = Minute (0 ... 59)
Dependency: Refer to: p8420, r8423
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
Description: Sets the switch-off time of the timer in hours and minutes.
BO: r8423 = 0 signal:
The condition for the set weekday (p8420) and switch-off time has been fulfilled.
Index: [0] = Hour (0 ... 23)
[1] = Minute (0 ... 59)
Dependency: Refer to: p8420, r8423
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
Description: Displays the output of timer 2.
The activated weekday (p8420) and the switch-on/off time (p8421/p8422) switch these two binector outputs.
Dependency: Refer to: p8420, p8421, p8422
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
p8421[0...1] RTC DTC2 switch-on time / RTC DTC2 t_ON
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 59 0
p8422[0...1] RTC DTC2 off time / RTC DTC2 t_OFF
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 59 0
r8423.0...1 BO: RTC DTC2 output / RTC DTC2 output
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Timer on Yes No -
01 Timer ON negated No Yes -
