List of Parameters
Parameters
1-237
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the PROFIBUS address of the sender from which the process data (PZD) is received.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
Note: Value range:
0 - 125: Bus address of the sender
255: Not assigned
Description: Displays the PZD byte offset in the PROFIdrive receive telegram (master output).
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
Note: Value range:
0 - 242: Byte offset
65535: Not assigned
Description: Displays the PZD byte offset in the PROFIdrive send telegram (master output).
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
Note: Value range:
0 - 242: Byte offset
65535: Not assigned
Description: Displays the addresses of the slaves (peers) where peer-to-peer data transfer has been configured via PROFIBUS.
r2074[0...7] PROFIdrive diagnostics bus address PZD receive / Diag addr recv
CU230P-2 DP Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2075[0...7] PROFIdrive diagnostics telegram offset PZD receive / Diag offs recv
CU230P-2 DP Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2076[0...7] PROFIdrive diagnostics telegram offset PZD send / Diag offs send
CU230P-2 DP Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2077[0...15] PROFIBUS diagnostics peer-to-peer data transfer addresses / PB diag peer addr
CU230P-2 DP Access level: 3 Calculated: - Data type: Unsigned8
Unit: - Scaling: - Data set: -
