Parameters
List of Parameters
1-34
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the instantaneous active power.
Index: [0] = Unsmoothed
[1] = Smoothed with p0045
[2] = Electric power
Dependency: Refer to: r0032
Note: The mechanical active power is available smoothed (r0032 with 100 ms, r0082[1] with p0045) and unsmoothed
(r0082[0]).
Description: Displays the flux setpoint.
Description: Displays the flux actual value.
Index: [0] = Unsmoothed
[1] = Smoothed
Description: Displays the actual active power factor.
Description: Displays the actual phase voltage.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
Note: The values are determined from the transistor power-on duration.
Description: Displays the transformation angle.
Dependency: Refer to: r1778
Note: The transformation angle corresponds to the electrical commutation angle.
r0082[0...2] CO: Active power actual value / P_act
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [kW] Scaling: r2004 Data set: -
r0083 CO: Flux setpoint / Flux setpoint
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
r0084[0...1] CO: Flux actual value / Flux act val
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
r0087 CO: Actual power factor / Cos phi act
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: - Data set: -
r0089[0...2] Actual phase voltage / U_phase act val
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [V] Scaling: p2001 Data set: -
r0094 CO: Transformation angle / Transformat_angle
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [°] Scaling: p2005 Data set: -
