Siemens CU230P-2 DP - p20228 CI: LIM 0 input X; LIM 0 input X; p20229 LIM 0 upper limit value LU; LIM 0 upper lim LU; p20230 LIM 0 lower limit value LL; LIM 0 lower lim LL; r20231 CO: LIM 0 output Y; LIM 0 output Y

Parameters
List of Parameters
1-382
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the signal source of input quantity X of instance LIM 0 of the limiter.
Description: Setting parameter for the upper limit value LU of instance LIM 0 of the limiter.
Description: Setting parameter for the lower limit value LL of instance LIM 0 of the limiter.
Description: Display parameter for the limited output quantity Y of instance LIM 0 of the limiter.
Description: Display parameter of instance LIM 0 of limiter QU (upper limit reached), i.e. QU = 1 for X >= LU.
Description: Display parameter of instance LIM 0 of limiter QL (lower limit reached), i.e. QL = 1 for X <= LL.
Description: Setting parameter for the run-time group in which instance LIM 0 of the limiter is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
p20228 CI: LIM 0 input X / LIM 0 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
p20229 LIM 0 upper limit value LU / LIM 0 upper lim LU
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
p20230 LIM 0 lower limit value LL / LIM 0 lower lim LL
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
r20231 CO: LIM 0 output Y / LIM 0 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
r20232 BO: LIM 0 input quantity at the upper limit QU / LIM 0 QU
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r20233 BO: LIM 0 input quantity at the lower limit QL / LIM 0 QL
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20234 LIM 0 run-time group / LIM 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
