List of Parameters
Parameters
1-315
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Activating access to parameters via manufacturer-specific CANopen objects and setting for the subindex area
(index 1) and the parameter area (index 2) when using virtual objects.
This means that it is possible to access all SINAMICS parameters via CAN.
Index 0:
0: Not possible to access virtual CANopen objects
1: Possible to access virtual CANopen objects
Index 1 (sub-index area):
0: 0 ... 255
1: 256 ... 511
2: 512 ... 767
3: 768 ... 1023
Index 2 (parameter area):
0: 1 ... 9999
1: 10000 ... 19999
2: 20000 ... 29999
3: 30000 ... 39999
Index: [0] = Drive object selection
[1] = Sub-index range
[2] = Parameter range
Description: Sets the drive behavior if a CAN communication error occurs.
Value: 0: No response
1: OFF1
2: OFF2
3: OFF3
Dependency: Refer to: F08700
Description: Displays the register of the CAN controller C_CAN:
Register, Message Interface Register and Message Handler Register - referred to the CAN protocol.
Index: [0] = Control register
[1] = Status register
[2] = Error counter
[3] = Bit timing register
[4] = Interrupt register
[5] = Test register
[6] = Baud rate prescaler extension register
[7] = Interface 1 command request register
[8] = Interface 1 command mask register
Note: A description of the individual registers of the C_CAN controller can be taken from "C_CAN User's Manual".
p8630[0...2] CAN virtual objects / Virtual objects
CU230P-2 CAN Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0 65535 0
p8641 CAN Abort Connection Option Code / Abort con opt code
CU230P-2 CAN Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 3 3
r8680[0...36] CAN Diagnosis Hardware / Diagnostics HW
CU230P-2 CAN Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
