Siemens CU230P-2 DP - p20355 MFP 2 pulse duration in ms; MFP 2 pulse_dur ms; r20356 BO: MFP 2 output Q; MFP 2 output Q; p20357 MFP 2 run-time group; MFP 2 RTG; p20358 MFP 2 run sequence; MFP 2 RunSeq

Parameters
List of Parameters
1-400
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for pulse duration T in milliseconds of instance MFP 2 of the pulse generator.
Description: Display parameter for output pulse Q of instance MFP 2 of the pulse generator.
Description: Setting parameter for the run-time group in which the instance MFP 2 of the pulse generator is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance MFP 2 within the run-time group set in p20357.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance MFP 3 of the pulse generator.
Description: Setting parameter for pulse duration T in milliseconds of instance MFP 3 of the pulse generator.
Description: Display parameter for output pulse Q of instance MFP 3 of the pulse generator.
p20355 MFP 2 pulse duration in ms / MFP 2 pulse_dur ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 60000.00 0.00
r20356 BO: MFP 2 output Q / MFP 2 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20357 MFP 2 run-time group / MFP 2 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20358 MFP 2 run sequence / MFP 2 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 950
p20359 BI: MFP 3 input pulse I / MFP 3 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
p20360 MFP 3 pulse duration in ms / MFP 3 pulse_dur ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 60000.00 0.00
r20361 BO: MFP 3 output Q / MFP 3 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
