Parameters
List of Parameters
1-180
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the status word of the speed controller.
Description: Displays the current controller status word.
Description: Sets the time constant for the speed setpoint filter 1 (PT1).
Description: Displays the speed setpoint after setpoint limiting for the P component of the speed controller.
For V/f operation, the value that is displayed is of no relevance.
Dependency: Refer to: r1439
Note: In the standard state (the reference model is deactivated), r1438 = r1439.
r1407.0...15 CO/BO: Status word speed controller / ZSW n_ctrl
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 V/f control active Yes No -
01 Encoderless operation active Yes No -
02 Torque control active Yes No 6030,
6060,
8010
03 Speed control active Yes No 6040
05 Speed controller I component frozen Yes No 6040
06 Speed controller I component set Yes No 6040
07 Torque limit reached Yes No 6060
08 Upper torque limit active Yes No 6060
09 Lower torque limit active Yes No 6060
10 Droop enabled Yes No 6030
11 Speed setpoint limited Yes No 6030
12 Ramp-function generator set Yes No -
13 Encoderless operation due to a fault Yes No -
15 Torque limit reached (without pre-control) Yes No 6060
r1408.0...12 CO/BO: Status word current controller / ZSW I_ctrl
Access level: 4 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Current ctrl act Active Not active -
01 Id control, I component limiting Active Not active 6714
03 Voltage limiting Active Not active 6714
10 Speed adaptation, limiting Active Not active -
12 Motor stalled Yes No 6719,
8018
p1416[0...n] Speed setpoint filter 1 time constant / n_set_filt 1 T
Access level: 4 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.00 [ms] 5000.00 [ms] 0.00 [ms]
r1438 CO: Speed controller, speed setpoint / n_ctrl n_set
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [rpm] Scaling: p2000 Data set: -
