Parameters
List of Parameters
1-92
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the debounce time for digital inputs.
Note: The digital inputs are read in cyclically every 2 ms (DI 11, DI 12 every 4 ms).
To debounce the signals, the set debounce time is converted into integer multiple debounce clock cycles Tp (Tp =
p0724 / 2 ms).
DI: Digital input
Description: Sets the signal source for terminal DO 0 (NO: T. 19 / NC: T. 18)
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: DO: Digital output
T: Terminal
Relay output: NO = normally open, NC = normally closed
Description: Sets the signal source for terminal DO 1 (NO: T. 21).
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: DO: Digital output
T: Terminal
Relay output: NO = normally open, NC = normally closed
Description: Sets the signal source for terminal DO 2 (NO: T. 24 / NC: T. 23).
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: DO: Digital Output
T: Terminal
Relay output: NO = normally open, NC = normally closed
p0724 CU digital inputs debounce time / CU DI t_debounce
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [ms] 20.000 [ms] 4.000 [ms]
p0730 BI: CU signal source for terminal DO 0 / CU S_src DO 0
Access level: 2 Calculated: - Data type: U32 / Binary
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
- - 52.3
p0731 BI: CU signal source for terminal DO 1 / CU S_src DO 1
Access level: 2 Calculated: - Data type: U32 / Binary
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
- - 52.7
p0732 BI: CU signal source for terminal DO 2 / CU S_src DO 2
Access level: 2 Calculated: - Data type: U32 / Binary
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
- - 52.2
