Siemens CU230P-2 DP - p20376 PLI 0 run-time group; PLI 0 RTG; p20377 PLI 0 run sequence; PLI 0 RunSeq; p20378 CI: PLI 1 input X; PLI 1 input X; r20379 CO: PLI 1 output Y; PLI 1 output Y

List of Parameters
Parameters
1-403
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run-time group in which instance PLI 0 of the polyline is to be called
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance PLI 0 within the run-time group set in p20376.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for input X of the polyline (20 breakpoints) of instance PLI 1.
Description: Display parameter for the output quantity Y of the polyline (20 breakpoints) of instance PLI 1
p20376 PLI 0 run-time group / PLI 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20377 PLI 0 run sequence / PLI 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 980
p20378 CI: PLI 1 input X / PLI 1 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
r20379 CO: PLI 1 output Y / PLI 1 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
