Siemens CU230P-2 DP User Manual

Function diagrams Technology controller 2-568
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Fig. 2-117 7951 – Fixed values, direct selection (p2216 = 1)
- 7951 -
Function diagram
87654321
FP_7951_97_51.vsd
Technology controller
G120 CU230P-2
29.10.2009 V4.3
Fixed values, direct selection (p2216 = 1)
+
++
0 0 0 1
0 0 1 0
1 0 0 0
0 1 0 0
+++
(722.3)
Tec_ctrl sel bit 0
p2220 [C]
(722.4)
Tec_ctrl sel bit 1
p2221 [C]
(722.5)
Tec_ctrl sel bit 2
p2222 [C]
(0)
Tec_ctrl sel bit 3
p2223 [C]
r2224
Tec_ctr FixVal eff [%]
Tec_ctrl fix val 1
-200.00 ... 200.00 [%]
p2201 [D] (10.00)
Tec_ctrl fix val 2
-200.00 ... 200.00 [%]
p2202 [D] (20.00)
Tec_ctrl fix val 3
-200.00 ... 200.00 [%]
p2203 [D] (30.00)
Tec_ctrl fix val 4
-200.00 ... 200.00 [%]
p2204 [D] (40.00)
Tec_ctrl FW status
r2225
r2225
