Siemens CU230P-2 DP - p20206 DFR 1 run-time group; DFR 1 RTG; p20207 DFR 1 run sequence; DFR 1 RunSeq; p20208[0...1] BI: BSW 0 inputs; BSW 0 inputs; p20209 BI: BSW 0 switch setting I; BSW 0 sw_setting

Parameters
List of Parameters
1-378
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run-time group in which instance DFR 1 of the D flipflop is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run-time group of instance DFR 1 within the run-time group set in p20206.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantities I0 and I1 of instance BSW 0 of the binary changeover switch.
Index: [0] = Input I0
[1] = Input I1
Description: Sets the signal source of the switch setting I of instance BSW 0 of the binary changeover switch.
Description: Display parameter for output quantity Q of instance BSW 0 of the binary changeover switch.
p20206 DFR 1 run-time group / DFR 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
1 9999 9999
p20207 DFR 1 run sequence / DFR 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 560
p20208[0...1] BI: BSW 0 inputs / BSW 0 inputs
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
p20209 BI: BSW 0 switch setting I / BSW 0 sw_setting
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
r20210 BO: BSW 0 output Q / BSW 0 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
