List of Parameters
Parameters
1-305
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets whether the real-time clock outputs an alarm if the time is not synchronized (e.g. if the power supply was
switched off for an extended period).
Value: 0: Alarm A01098 deactivated
1: Alarm A01098 activated
Dependency: Refer to: A01098
Note: RTC: Real-time clock
Description: Sets the weekday on which timer 1 is activated.
The switch-on/off time is set in p8411/p8412 and the result displayed via binector output r8413.
Value: 0: Weekday deactivated
1: Weekday activated
Index: [0] = Monday
[1] = Tuesday
[2] = Wednesday
[3] = Thursday
[4] = Friday
[5] = Saturday
[6] = Sunday
Dependency: Refer to: p8411, p8412, r8413
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
Description: Sets the switch-on time of the timer in hours and minutes.
BO: r8413 = 1 signal:
The condition for the set weekday (p8410) and switch-on time has been fulfilled.
Index: [0] = Hour (0 ... 23)
[1] = Minute (0 ... 59)
Dependency: Refer to: p8410, r8413
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
p8405 Activate/deactivate RTC alarm A01098 / RTC A01098 act
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0000 bin 0001 bin 0001 bin
p8410[0...6] RTC DTC1 weekday of activation / RTC DTC1 day act
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0000 bin 0001 bin 0000 bin
p8411[0...1] RTC DTC1 switch-on time / RTC DTC1 t_ON
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 59 0
