Parameters
List of Parameters
1-90
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Selects the function for digital input 12.
Value: 0: No pre-assignment
1: ON/OFF1
3: 2. OFF2
4: 2. OFF3
9: 2. Acknowledge faults
10: Jog bit 0
11: Jog bit 1
12: Direction reversal
13: Motorized potentiometer setpoint raise
14: Motorized potentiometer lower setpoint
15: Fixed speed setpoint selection Bit 0
16: Fixed speed setpoint selection Bit 1
17: Fixed speed setpoint selection Bit 2
18: Fixed speed setpoint selection Bit 3
25: Activate DC brake
26: Activate emergency operation
27: Enable technology controller
29: External fault 1
35: Command data set selection CDS bit 0
50: Load monitoring failure detection
Warning: It is possible to interconnect the digital input with several signal sinks using BICO parameterization without this
parameter providing a message. As a result of the corresponding BICO parameterization, for example, the drive
could undesirably accelerate without this function having been selected in this parameter.
Note: When changing the function within the selection possibilities, the previously selected interconnection is discon-
nected by resetting the signal sink.
However, the selected function is protected against being changed by BICO parameterization, i.e. the signal sink
must first be enabled using "no pre-assignment" before it can be interconnected again.
Description: Displays the number of inputs and outputs
Index: [0] = Number of digital inputs
[1] = Number of digital outputs
[2] = Number of digital input/outputs bidirectional
[3] = Number of analog inputs
[4] = Number of analog outputs
p0713[0...n] Pre-assignment digital input 12 / Pre-assign. DI12
PM240 Access level: 2 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: CDS, p0170
Min Max Factory setting
0 50 0
r0720[0...4] CU number of inputs and outputs / CU I/O count
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
