Siemens CU230P-2 DP - r8750[0...15] CAN mapped 16-bit receive objects; RPDO 16 mapped; r8751[0...15] CAN mapped 16-bit transmit objects; TPDO 16 mapped

Parameters
List of Parameters
1-328
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the mapped 16-bit receive CANopen objects in the process data buffer.
Example:
If, e.g. the control word is mapped in an RPDO, then r8750 indicates the position of the control word in the process
data buffer.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
Description: Displays mapped 16-bit transmit CANopen objects in the process data buffer.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
Dependency: Refer to: r8750
r8750[0...15] CAN mapped 16-bit receive objects / RPDO 16 mapped
CU230P-2 CAN Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r8751[0...15] CAN mapped 16-bit transmit objects / TPDO 16 mapped
CU230P-2 CAN Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
