List of Parameters
Parameters
1-179
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the configuration for flux setpoint control
Note: Re bit 00 (not for permanent-magnet synchronous motors):
Initially, the flux is only established with a low rate of rise when magnetizing the induction motor. The flux setpoint
p1570 is reached again at the end of the magnetizing time p0346.
Re bit 01 (not for permanent-magnet synchronous motors):
Initially, the flux is only established with a low rate of rise when magnetizing the induction motor. The flux setpoint
p1570 is reached again at the end of the magnetizing time p0346. When quick magnetizing (p1401.6 = 1) is
selected, soft starting is internally deactivated and alarm A07416 is displayed.
The flux differentiation can be switched out if a significant ripple occurs in the field-generating current setpoint
(r0075) when entering the field weakening range. However, this is not suitable for fast acceleration operations
because then, the flux decays more slowly and the voltage limiting responds.
Re bit 02 (not for permanent-magnet synchronous motors):
The flux build-up control operates during the magnetizing phase p0346 of the induction motor. If it is switched out, a
constant current setpoint is injected and the flux is built up corresponding to the rotor time constant. When quick
magnetizing (p1401.6 = 1) is selected and when flux build-up control is de-energized alarm A07416 is displayed.
Re bit 06 (not for induction motors):
Magnetizing is performed with maximum current (0.9 * r0067). With active identification of the stator resistance (see
p0621) quick magnetizing is internally deactivated and alarm A07416 is displayed. During a flying restart of a rotat-
ing motor (see p1200) no quick magnetizing takes place.
Re bit 07:
if the speed of the drive exceeds the effective speed limit of the speed limiting controller, the torque limit is reduced
linearly to zero as the deviation becomes greater. This reduces the integral component of the speed controller and,
in turn, the overshoot during load shedding (see also F07901 and p2162).
Description: Sets the configuration for the closed-loop control and the motor model.
Description: Displays the control word of the speed controller.
p1401[0...n] Flux control configuration / Flux ctrl config
Access level: 4 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
- - 0110 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Flux setpoint soft starting active Yes No 6722
01 Flux setpoint differentiation active Yes No 6723
02 Flux build-up control active Yes No 6722, 6723
06 Quick magnetizing Yes No 6722
07 Pre-control speed limitation Yes No 6640
p1402[0...n] Closed-loop current control and motor model configuration / I_ctrl config
Access level: 4 Calculated: p0340 = 1,3 Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
- - 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
02 Current controller adaptation active Yes No -
r1406.4...15 CO/BO: Control word speed controller / STW n_ctrl
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
04 Hold speed controller I component Yes No 6040
05 Set speed controller I component Yes No 6040
11 Droop enable Yes No 6030
12 Torque control active Yes No 6060
15 Set speed adaptation controller I compo-
nent
Yes No -
