Page #358 background image
Parameters
List of Parameters
1-358
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Display parameter for the inverted output of instance NOT 1 of the inverter.
Description: Setting parameter for the run-time group in which the instance NOT 1 of the inverter is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance NOT 1 within the run-time group set in p20084.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantity I of instance NOT 2 of the inverter.
Description: Display parameter for the inverted output of instance NOT 2 of the inverter.
Description: Setting parameter for the run-time group in which the instance NOT 2 of the inverter is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
r20083 BO: NOT 1 inverted output / NOT 1 inv output
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20084 NOT 1 run-time group / NOT 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
1 9999 9999
p20085 NOT 1 run sequence / NOT 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 170
p20086 BI: NOT 2 input I / NOT 2 input I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
r20087 BO: NOT 2 inverted output / NOT 2 inv output
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20088 NOT 2 run-time group / NOT 2 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
1 9999 9999
