Parameters
List of Parameters
1-306
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the switch-off time of the timer in hours and minutes.
BO: r8413 = 0 signal:
The condition for the set weekday (p8410) and switch-off time has been fulfilled.
Index: [0] = Hour (0 ... 23)
[1] = Minute (0 ... 59)
Dependency: Refer to: p8410, r8413
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
Description: Displays the output of timer 1.
The activated weekday (p8410) and the switch-on/off time (p8411/p8412) switch these two binector outputs.
Dependency: Refer to: p8410, p8411, p8412
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
Description: Sets the weekday on which timer 2 is activated.
The switch-on/off time is set in p8421/p8422 and the result displayed via binector output r8423.
Value: 0: Weekday deactivated
1: Weekday activated
Index: [0] = Monday
[1] = Tuesday
[2] = Wednesday
[3] = Thursday
[4] = Friday
[5] = Saturday
[6] = Sunday
Dependency: Refer to: p8421, p8422, r8423
Note: DTC: Digital Time Clock (timer)
RTC: Real-time clock
p8412[0...1] RTC DTC1 off time / RTC DTC1 t_OFF
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 59 0
r8413.0...1 BO: RTC DTC1 output / RTC DTC1 output
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Timer on Yes No -
01 Timer ON negated No Yes -
p8420[0...6] RTC DTC2 weekday of activation / RTC DTC2 day act
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0000 bin 0001 bin 0000 bin
