Siemens CU230P-2 DP - r20001[0...9] Run-time group sampling time; RTG sampling time; p20030[0...3] BI: AND 0 inputs; AND 0 inputs; r20031 BO: AND 0 output Q; AND 0 output Q; p20032 AND 0 run-time group; AND 0 RTG

Parameters
List of Parameters
1-348
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the current sampling time of the run-time group 0 to 9.
Index: [0] = Run-time group 0
[1] = Run-time group 1
[2] = Run-time group 2
[3] = Run-time group 3
[4] = Run-time group 4
[5] = Run-time group 5
[6] = Run-time group 6
[7] = Run-time group 7
[8] = Run-time group 8
[9] = Run-time group 9
Description: Sets the signal source of input quantities I0, I1, I2, I3 of instance AND 0 of the AND function block.
Index: [0] = Input I0
[1] = Input I1
[2] = Input I2
[3] = Input I3
Description: Display parameter for binary quantity Q = I0 & I1 & I2 & I3 of instance AND 0 of the AND function block.
Description: Setting parameter for the run-time group in which the instance AND 0 of the AND function block is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance AND 0 within the run-time group set in p20032.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
r20001[0...9] Run-time group sampling time / RTG sampling time
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [ms] Scaling: - Data set: -
p20030[0...3] BI: AND 0 inputs / AND 0 inputs
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
r20031 BO: AND 0 output Q / AND 0 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20032 AND 0 run-time group / AND 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
1 9999 9999
p20033 AND 0 run sequence / AND 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 10
