Description: Sets skip speed 3.
Dependency: Refer to: p1091, p1092, p1094, p1101
Description: Sets skip speed 4.
Dependency: Refer to: p1091, p1092, p1093, p1101
Description: Sets the bandwidth for the skip speeds/velocities 1 to 4.
Dependency: Refer to: p1091, p1092, p1093, p1094
Note: The setpoint (reference) speeds are skipped (suppressed) in the range of the skip speed +/-p1101.
Steady-state operation is not possible in the skipped (suppressed) speed range. The skip (suppression) range is
skipped.
Example:
p1091 = 10 and p1101 = 0.3
--> Setpoint speeds between 9.7 and 10.3 [Hz] are skipped.
For the skip bandwidths, the following hysteresis behavior applies:
For a setpoint speed coming from below, the following applies:
r1170 < 9.7 [Hz] and 9.7 [Hz] <= r1114 <= 10.3 [Hz] --> r1119 = 9.7 [Hz]
For a setpoint speed coming from above, the following applies:
r1170 > 10.3 [Hz] and 9.7 [Hz] <= r1114 <= 10.3 [Hz] --> r1119 = 10.3 [Hz]
Description: Sets the signal source to select the total setpoint.
Dependency: The selection of the total speed setpoint is automatically interconnected to the status word of the technology con-
troller (r2349.4) if the technology controller is selected (p2200 > 0) and operated in the mode p2251 = 0. If the hiber-
nation function is activated (p2398 = 1), an interconnection is made to r2399 bit 7.
Refer to: p1109
Caution: If the technology controller is to supply the total setpoint using p1109, then it is not permissible to withdraw the inter-
connection to its status word (r2349.4). If the hibernation function is activated, then it is not permissible to withdraw
the interconnection to status word r2399.
p1093[0...n] Skip speed 3 / n_skip 3
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: p2000 Data set: DDS, p0180
Min Max Factory setting
0.000 [rpm] 210000.000 [rpm] 0.000 [rpm]
p1094[0...n] Skip speed 4 / n_skip 4
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: p2000 Data set: DDS, p0180
Min Max Factory setting
0.000 [rpm] 210000.000 [rpm] 0.000 [rpm]
p1101[0...n] Skip speed bandwidth / n_skip bandwidth
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: p2000 Data set: DDS, p0180
Min Max Factory setting
0.000 [rpm] 210000.000 [rpm] 0.000 [rpm]
p1108[0...n] BI: Total setpoint selection / Total setp sel
Access level: 4 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: CDS, p0170
Min Max Factory setting
- - 0
