Page #254 background image
Parameters
List of Parameters
1-254
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays additional information about the active alarm for float values.
Dependency: Refer to: r2110, r2122, r2123, r2124, r2125, r2145, r2146
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
Description: Displays the second status word of faults and alarms.
Description: Displays the system runtime in days when the fault was removed.
Dependency: Refer to: r0945, r0947, r0948, r0949, r2109, r2130, r2133, p8401
Notice: The time comprises r2136 (days) and r2109 (milliseconds).
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
Description: Displays the control word of the faults and alarms.
Dependency: Refer to: p2103, p2104, p2105, p2106, p2107, p2108, p2112, p2116, p2117, p3110, p3111, p3112
r2134[0...63] Alarm value for float values / Alarm value float
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: - Data set: -
r2135.12...15 CO/BO: Status word faults/alarms 2 / ZSW fault/alarm 2
Access level: 2 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
12 Fault motor overtemperature Yes No -
13 Fault power unit thermal overload Yes No -
14 Alarm motor overtemperature Yes No -
15 Alarm power unit thermal overload Yes No -
r2136[0...63] Fault time removed in days / t_flt resolv. days
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
r2138.7...15 CO/BO: Control word faults/alarms / STW fault/alarm
Access level: 2 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
07 Acknowledge fault Yes No -
10 External alarm 1 (A07850) effective Yes No -
11 External alarm 2 (A07851) effective Yes No -
12 External alarm 3 (A07852) effective Yes No -
13 External fault 1 (F07860) effective Yes No -
14 External fault 2 (F07861) effective Yes No -
15 External fault 3 (F07862) effective Yes No -
