Siemens CU230P-2 DP - r0721 CU digital inputs, terminal actual value; CU DI actual value; r0722.0...12 CO;BO: CU digital inputs, status; CU DI status; r0723.0...12 CO;BO: CU digital inputs, status inverted; CU DI status inv

List of Parameters
Parameters
1-91
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the actual value at the digital inputs.
This means that the actual input signal can be checked at terminal DI x prior to switching from the simulation mode
(p0795.x = 1) to the terminal mode (p0795.x = 0). The input signal at terminal DI x is displayed in bit x of r0721.
Note: DI: Digital input
AI: Analog Input
T: Terminal
Description: Displays the status of the digital inputs.
Dependency: Refer to: r0723
Note: DI: Digital input
AI: Analog Input
T: Terminal
Description: Displays the inverted status of the digital inputs.
Dependency: Refer to: r0722
Note: DI: Digital input
AI: Analog Input
T: Terminal
r0721 CU digital inputs, terminal actual value / CU DI actual value
Access level: 2 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
04 DI 4 (T. 16) High Low -
05 DI 5 (T. 17) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
12 DI 12 (T. 10, 11) AI 1 High Low -
r0722.0...12 CO/BO: CU digital inputs, status / CU DI status
Access level: 2 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
04 DI 4 (T. 16) High Low -
05 DI 5 (T. 17) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
12 DI 12 (T. 10, 11) AI 1 High Low -
r0723.0...12 CO/BO: CU digital inputs, status inverted / CU DI status inv
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
04 DI 4 (T. 16) High Low -
05 DI 5 (T. 17) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
12 DI 12 (T. 10, 11) AI 1 High Low -
