Siemens CU230P-2 DP User Manual

List of Parameters
Parameters
1-35
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Defines whether the motor and drive converter power settings (e.g. rated motor power - p0307) are expressed in
[kW] or [hp].
Depending on the selection, the rated motor frequency (p0310) is either set to 50 Hz or 60 Hz.
The following applies for IEC drives: The power factor (p0308) should be parameterized.
The following applies for NEMA drives: The efficiency (p0309) should be parameterized.
Value: 0: IEC-Motor (50 Hz, SI units)
Dependency: If p0100 is changed, all of the rated motor parameters are reset. Only then are possible unit changeovers made.
The units of all motor parameters are changed that are involved in the selection of IEC or NEMA (e.g. r0206, p0307,
r0333, r0334, p0341, p0344, r1969).
Refer to: r0206, p0210, p0300, p0304, p0305, p0307, p0308, p0310, p0311, p0314, p0320, p0322, p0323, p0335,
r0337, p1800
Note: The parameter value is not reset when the factory setting is restored (p0010 = 30, p0970).
The extension of the parameter to p0100 = 1 (NEMA) will be realized in a later software version.
Description: Sets the number of Command Data Sets (CDS).
Dependency: Refer to: p0010
Note: It is possible to toggle between command parameters (BICO parameters) using this data set changeover.
Description: Sets the number of Drive Data Sets (DDS).
Dependency: Refer to: p0010
Description: Displays the bootloader version.
Dependency: Refer to: r0018, r0198
Note: Example:
The value 1010100 should be interpreted as V01.01.01.00.
p0100 IEC/NEMA mot stds / IEC/NEMA mot stds
Access level: 4 Calculated: - Data type: Integer16
Can be changed: C(1) Scaling: - Data set: -
Min Max Factory setting
0 0 0
p0170 Number of Command Data Sets (CDS) / CDS count
Access level: 2 Calculated: - Data type: Unsigned8
Can be changed: C(15) Scaling: - Data set: -
Min Max Factory setting
2 4 2
p0180 Number of Drive Data Sets (DDS) / DDS count
Access level: 3 Calculated: - Data type: Unsigned8
Can be changed: C(15) Scaling: - Data set: -
Min Max Factory setting
1 4 1
r0197 Bootloader version / Bootloader vers
Access level: 4 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
