Parameters
List of Parameters
1-390
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Display parameter of instance LVM 1 of the double-sided limiter that input quantity X was at least once X < M - L
and X is <= M - L + HY.
Description: Setting parameter for the run-time group in which instance LVM 1 of the double-sided limiter is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance LVM within the run-time group set in p20282.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantity X of instance DIF 0 of the differentiating element.
Description: Sets the differentiating time constant Td in milliseconds of instance DIF 0 of the differentiating element.
Description: Display parameter for output quantity Y of instance DIF 0 of the differentiating element.
r20281 BO: LVM 1 input quantity below interval QL / LVM 1 X below QL
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20282 LVM 1 run-time group / LVM 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20283 LVM 1 run sequence / LVM 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 7999 730
p20284 CI: DIF 0 input X / DIF 0 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
p20285 DIF 0 differentiating time constant in ms / DIF 0 T_diff ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 340.28235E36 0.00
r20286 CO: DIF 0 output Y / DIF 0 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
