Siemens CU230P-2 DP - r20125 BO: DIV 1 divisor is zero QF; DIV 1 divisor=0 QF; p20126 DIV 1 run-time group; DIV 1 RTG; p20127 DIV 1 run sequence; DIV 1 RunSeq; p20128 CI: AVA 0 input X; AVA 0 input X

List of Parameters
Parameters
1-365
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Display parameter for the signal QF that the divisor X2 of instance DIV 1 of the divider is zero.
X2 = 0.0 => QF = 1
Description: Setting parameter for the run-time group in which instance DIV 1 of the divider is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance DIV 1 within the run-time group set in p20126.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of the input quantity X of instance AVA 0 of the absolute value generator with sign evalua-
tion.
Description: Display parameter for output quantity Y of instance AVA 0 of the absolute value generator with sign evaluation.
Description: Display parameter for signal SN that the input quantity X of instance AVA 0 of the absolute value generator with
sign evaluation is negative.
X < 0.0 => SN = 1
r20125 BO: DIV 1 divisor is zero QF / DIV 1 divisor=0 QF
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20126 DIV 1 run-time group / DIV 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20127 DIV 1 run sequence / DIV 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 310
p20128 CI: AVA 0 input X / AVA 0 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
r20129 CO: AVA 0 output Y / AVA 0 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
r20130 BO: AVA 0 input negative SN / AVA 0 input neg SN
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
