Siemens CU230P-2 DP - p0205 Power unit application; PU application; r0206[0...4] Rated power unit power; PU P_rated; r0207[0...4] Rated power unit current; PU PI_rated; r0208 Rated power unit line supply voltage; PU V_rated

Parameters
List of Parameters
1-38
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: The duty cycles can be overloaded provided that the drive converter is operated with its base load current before
and after the overload. This is based on a load duty cycle of 300 s.
Value: 0: Load duty cycle with high overload for vector drives
1: Load duty cycle with low overload for vector drives
Notice: The parameter value is not reset when the factory setting is restored (see p0010 = 30, p0970).
Note: When the parameter is changed, all of the motor parameters, the technological application and the control mode
are pre-assigned according to the selected application. The parameter has not influence when calculating the ther-
mal overload.
p0205 can only be changed to the settings that are saved in the power unit EEPROM.
Description: Displays the rated power unit power for various load duty cycles.
Index: [0] = Rated value
[1] = Load duty cycle with low overload
[2] = Load duty cycle with high overload
[3] = Reserved
[4] = Reserved
Dependency: IECdrives (p0100 = 0): Units kW
NEMA drives (p0100 = 1): Units hp
Refer to: p0100, p0205
Description: Displays the rated power unit power for various load duty cycles.
Index: [0] = Rated value
[1] = Load duty cycle with low overload
[2] = Load duty cycle with high overload
[3] = Reserved
[4] = Reserved
Dependency: Refer to: p0205
Description: Displays the rated line supply voltage of the power unit.
r0208 = 400 : 380 - 480 V +/-10 %
r0208 = 500 : 500 - 600 V +/-10 %
r0208 = 690 : 660 - 690 V +/-10 %
p0205 Power unit application / PU application
PM240
PM250, PM260
Access level: 1 Calculated: - Data type: Integer16
Can be changed: C(1, 2) Scaling: - Data set: -
Min Max Factory setting
0 1 0
r0206[0...4] Rated power unit power / PU P_rated
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [kW] Scaling: - Data set: -
r0207[0...4] Rated power unit current / PU PI_rated
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [Arms] Scaling: - Data set: -
r0208 Rated power unit line supply voltage / PU V_rated
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [Vrms] Scaling: - Data set: -
