Siemens CU230P-2 DP - r11272 CO: Free tec_ctrl 2 actual value after limiter; Ftec2 act v af lim; r11273 CO: Free tec_ctrl 2 system deviation; Ftec2 sys dev; p11274 Free tec_ctrl 2 differentiation time constant; Ftec2 D comp T; p11280 Free tec_ctrl 2 proportional gain; Ftec2 Kp

Parameters
List of Parameters
1-346
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Display and connector output for the actual value after the limiter of the free technology controller 2.
Description: Display and connector output for the system deviation of the free technology controller 2.
Description: Sets the time constant for the differentiation (D component) of the free technology controller 2.
Note: Value = 0: Differentiation is deactivated.
Description: Sets the proportional gain (P component) of the free technology controller 2.
Note: Value = 0: The proportional gain is deactivated.
Description: Sets the integral time (I component, integrating time constant) of the free technology controller 2.
Note: Value = 0: The integral time is disabled.
If the parameter is set to zero during operation, the I component retains its most recent value.
Description: Sets the maximum limit of the free technology controller 2.
Dependency: Refer to: p11292
Note: The maximum limit must always be greater than the minimum limit (p11291 > p11292).
Description: Sets the minimum limit of the free technology controller 2.
Dependency: Refer to: p11291
Note: The maximum limit must always be greater than the minimum limit (p11291 > p11292).
r11272 CO: Free tec_ctrl 2 actual value after limiter / Ftec2 act v af lim
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
r11273 CO: Free tec_ctrl 2 system deviation / Ftec2 sys dev
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
p11274 Free tec_ctrl 2 differentiation time constant / Ftec2 D comp T
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [s] 60.000 [s] 0.000 [s]
p11280 Free tec_ctrl 2 proportional gain / Ftec2 Kp
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 1000.000 1.000
p11285 Free tec_ctrl 2 integral time / Ftec2 Tn
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [s] 10000.000 [s] 30.000 [s]
p11291 CO: Free tec_ctrl 2 limit maximum / Ftec2 lim max
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
-200.00 [%] 200.00 [%] 100.00 [%]
p11292 CO: Free tec_ctrl 2 limit minimum / Ftec2 lim min
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
