Siemens CU230P-2 DP User Manual

Technology controller
Function diagrams
2-567
© Siemens AG 2009 All Rights Reserved SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Fig. 2-116 7950 – Fixed values, binary selection (p2216 = 2)
- 7950 -
Function diagram
87654321
FP_7950_97_51.vsd
Technology controller
G120 CU230P-2
29.10.2009 V4.3
Fixed values, binary selection (p2216 = 2)
0 1 1 0
1 0 1 0
1 1 0 0
1 1 1 0
0 0 0 1
0 0 1 0
0 0 0 0
0 1 0 0
1 0 0 0
0.00 %
0 1 1 1
1 1 1 1
1 1 0 1
1 0 1 1
0 0 1 1
0 1 0 1
1 0 0 1
0 ... 15
2
0
2
3
(722.3)
Tec_ctrl sel bit 0
p2220 [C]
(722.4)
Tec_ctrl sel bit 1
p2221 [C]
(722.5)
Tec_ctrl sel bit 2
p2222 [C]
(0)
Tec_ctrl sel bit 3
p2223 [C]
Tec_ctrl No. act
r2229
r2224
Tec_ctr FixVal eff [%]
Tec_ctrl fix val 1
-200.00 ... 200.00 [%]
p2201 [D] (10.00)
Tec_ctrl fix val 2
-200.00 ... 200.00 [%]
p2202 [D] (20.00)
Tec_ctrl fix val 3
-200.00 ... 200.00 [%]
p2203 [D] (30.00)
Tec_ctrl fix val 4
-200.00 ... 200.00 [%]
p2204 [D] (40.00)
Tec_ctrl fix val 5
-200.00 ... 200.00 [%]
p2205 [D] (50.00)
Tec_ctrl fix val 6
-200.00 ... 200.00 [%]
p2206 [D] (60.00)
Tec_ctrl fix val 7
-200.00 ... 200.00 [%]
p2207 [D] (70.00)
Tec_ctrl fix val 8
-200.00 ... 200.00 [%]
p2208 [D] (80.00)
Tec_ctrl fix val 9
-200.00 ... 200.00 [%]
p2209 [D] (90.00)
Tec_ctrl fix val10
-200.00 ... 200.00 [%]
p2210 [D] (100.00)
Tec_ctrl fix val11
-200.00 ... 200.00 [%]
p2211 [D] (110.00)
Tec_ctrl fix val12
-200.00 ... 200.00 [%]
p2212 [D] (120.00)
Tec_ctrl fix val13
-200.00 ... 200.00 [%]
p2213 [D] (130.00)
Tec_ctrl fix val14
-200.00 ... 200.00 [%]
p2214 [D] (140.00)
Tec_ctrl fix val15
-200.00 ... 200.00 [%]
p2215 [D] (150.00)
Tec_ctrl FW status
r2225
r2225
