Siemens CU230P-2 DP - r0056.0...13 CO;BO: Status word, closed-loop control; ZSW cl�loop ctrl; r0060 CO: Speed setpoint before the setpoint filter; n_set before filt.; r0062 CO: Speed setpoint after the filter; n_set after filter; r0063[0...2] CO: Actual speed value; n_act

Parameters
List of Parameters
1-30
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the status word of the closed-loop control.
Description: Displays the actual speed setpoint at the input of the speed controller or V/f characteristic (after the interpolator).
Dependency: Refer to: r0020
Note: The speed setpoint is available smoothed (r0020) and unsmoothed (r0060).
Description: Displays the actual speed setpoint after the setpoint filters.
Description: Displays the actual speed of the closed-loop speed control and the V/f control.
Index: [0] = Unsmoothed
[1] = Smoothed with p0045
[2] = Calculated from f_set - f_slip
Dependency: Refer to: r0021
Note: The speed actual value r0063[0] is additionally displayed - smoothed with p0045 - in r0063[1].
The speed (r0063[2]) calculated from the output frequency and slip can only be compared with the speed actual
value (r0063[0]) in the steady-state.
Description: Displays the actual system deviation of the speed controller.
r0056.0...13 CO/BO: Status word, closed-loop control / ZSW cl-loop ctrl
PM250
PM260
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Initialization completed Yes No -
01 Demagnetizing completed Yes No -
02 Pulse enable present Yes No -
03 Soft starting present Yes No -
04 Magnetizing completed Yes No -
05 Voltage boost when starting Active Inactive 6300
06 Acceleration voltage Active Inactive 6300
07 Frequency negative Yes No 6719
08 Field weakening active Yes No -
09 Voltage limit active Yes No 6714
10 Slip limit active Yes No 6310
11 Frequency limit active Yes No 6719
12 Current limiting controller voltage output
active
Yes No -
13 Current/torque limiting Active Inactive 6060
r0060 CO: Speed setpoint before the setpoint filter / n_set before filt.
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [rpm] Scaling: p2000 Data set: -
r0062 CO: Speed setpoint after the filter / n_set after filter
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [rpm] Scaling: p2000 Data set: -
r0063[0...2] CO: Actual speed value / n_act
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [rpm] Scaling: p2000 Data set: -
r0064 CO: Speed controller system deviation / n_ctrl system dev
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [rpm] Scaling: p2000 Data set: -
