Siemens CU230P-2 DP - r11072 CO: Free tec_ctrl 0 actual value after limiter; Ftec0 act v af lim; r11073 CO: Free tec_ctrl 0 system deviation; Ftec0 sys dev; p11074 Free tec_ctrl 0 differentiation time constant; Ftec0 D comp T; p11080 Free tec_ctrl 0 proportional gain; Ftec0 Kp

Parameters
List of Parameters
1-338
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Display and connector output for the actual value after the limiter of the free technology controller 0.
Description: Display and connector output for the system deviation of the free technology controller 0.
Description: Sets the time constant for the differentiation (D component) of the free technology controller 0.
Note: Value = 0: Differentiation is deactivated.
Description: Sets the proportional gain (P component) of the free technology controller 0.
Note: Value = 0: The proportional gain is deactivated.
Description: Sets the integral time (I component, integrating time constant) of the free technology controller 0.
Note: Value = 0: The integral time is disabled.
If the parameter is set to zero during operation, the I component retains its most recent value.
Description: Sets the maximum limit of the free technology controller 0.
Dependency: Refer to: p11092
Note: The maximum limit must always be greater than the minimum limit (p11091 > p11092).
Description: Sets the minimum limit of the free technology controller 0.
Dependency: Refer to: p11091
Note: The maximum limit must always be greater than the minimum limit (p11091 > p11092).
r11072 CO: Free tec_ctrl 0 actual value after limiter / Ftec0 act v af lim
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
r11073 CO: Free tec_ctrl 0 system deviation / Ftec0 sys dev
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
p11074 Free tec_ctrl 0 differentiation time constant / Ftec0 D comp T
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [s] 60.000 [s] 0.000 [s]
p11080 Free tec_ctrl 0 proportional gain / Ftec0 Kp
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 1000.000 1.000
p11085 Free tec_ctrl 0 integral time / Ftec0 Tn
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [s] 10000.000 [s] 30.000 [s]
p11091 CO: Free tec_ctrl 0 limit maximum / Ftec0 lim max
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
-200.00 [%] 200.00 [%] 100.00 [%]
p11092 CO: Free tec_ctrl 0 limit minimum / Ftec0 lim min
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
