Siemens CU230P-2 DP - p20287 DIF 0 run-time group; DIF 0 RTG; p20288 DIF 0 run sequence; DIF 0 RunSeq; p20300 BI: NOT 4 input I; NOT 4 input I; r20301 BO: NOT 4 inverted output; NOT 4 inv output

List of Parameters
Parameters
1-391
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run-time group in which instance DIF 0 of the differentiating element is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance DIF 0 within the run-time group set in p20287.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantity I of instance NOT 4 of the inverter.
Description: Display parameter for the inverted output of instance NOT 4 of the inverter.
Description: Setting parameter for the run-time group in which the instance NOT 4 of the inverter is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance NOT 4 within the run-time group set in p20302.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
p20287 DIF 0 run-time group / DIF 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20288 DIF 0 run sequence / DIF 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 750
p20300 BI: NOT 4 input I / NOT 4 input I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
r20301 BO: NOT 4 inverted output / NOT 4 inv output
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20302 NOT 4 run-time group / NOT 4 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
1 9999 9999
p20303 NOT 4 run sequence / NOT 4 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 770
