Parameters
List of Parameters
1-212
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the modulator mode.
Value: 0: Automatic changeover SVM/FLB
2: Space vector modulation (SVM)
3: SVM without overcontrol
4: SVM/FLB without overcontrol
10: SVM/FLB with modulation depth reduction
Dependency: If a sine-wave filter is parameterized as output filter (p0230 = 3, 4), then only space vector modulation without over-
control can be selected as modulation type (p1802 = 3).
Refer to: p0230
Note: When modulation modes are enabled that could lead to overmodulation (p1802 = 0, 2), the modulation depth must
be limited using p1803 (pre-assignment, p1803 = 98%). The higher the overmodulation, the greater the current rip-
ple and torque ripple.
When changing p1802[x], the values for all of the other existing indices are also changed.
Description: Sets the modulator mode.
Value: 0: Automatic changeover SVM/FLB
2: Space vector modulation (SVM)
3: SVM without overcontrol
4: SVM/FLB without overcontrol
Dependency: If a sine-wave filter is parameterized as output filter (p0230 = 3, 4), then only space vector modulation without over-
control can be selected as modulation type (p1802 = 3).
Refer to: p0230
Note: When modulation modes are enabled that could lead to overmodulation (p1802 = 0, 2), the modulation depth must
be limited using p1803 (pre-assignment, p1803 = 98%). The higher the overmodulation, the greater the current rip-
ple and torque ripple.
When changing p1802[x], the values for all of the other existing indices are also changed.
Description: Defines the maximum modulation depth.
Note: p1803 = 100% is the overcontrol limit for space vector modulation (for an ideal drive converter without any switching
delay).
Description: Defines the maximum modulation depth.
Note: p1803 = 100% is the overcontrol limit for space vector modulation (for an ideal drive converter without any switching
delay).
p1802[0...n] Modulator mode / Modulator mode
PM240 Access level: 3 Calculated: p0340 = 1,3,5 Data type: Integer16
Can be changed: T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 10 0
p1802[0...n] Modulator mode / Modulator mode
PM250
PM260
Access level: 3 Calculated: p0340 = 1,3,5 Data type: Integer16
Can be changed: T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 4 4
p1803[0...n] Maximum modulation depth / Modulat depth max
PM230 Access level: 4 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
20.0 [%] 120.0 [%] 115.0 [%]
p1803[0...n] Maximum modulation depth / Modulat depth max
PM230
PM250, PM260
Access level: 4 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
20.0 [%] 120.0 [%] 100.0 [%]
