Siemens CU230P-2 DP - p20131 AVA 0 run-time group; AVA 0 RTG; p20132 AVA 0 run sequence; AVA 0 RunSeq; p20133 CI: AVA 1 input X; AVA 1 input X; r20134 CO: AVA 1 output Y; AVA 1 output Y

Parameters
List of Parameters
1-366
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run-time group in which instance AVA 0 of the absolute value generator with sign evalua-
tion is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance AVA 0 within the run-time group set in p20131.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of the input quantity X of instance AVA 1 of the absolute value generator with sign evalua-
tion.
Description: Display parameter for output quantity Y of instance AVA 1 of the absolute value generator with sign evaluation.
Description: Display parameter for signal SN that the input quantity X of instance AVA 1 of the absolute value generator with
sign evaluation is negative.
X < 0.0 => SN = 1
Description: Setting parameter for the run-time group in which instance AVA 1 of the absolute value generator with sign evalua-
tion is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
p20131 AVA 0 run-time group / AVA 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20132 AVA 0 run sequence / AVA 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 340
p20133 CI: AVA 1 input X / AVA 1 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
r20134 CO: AVA 1 output Y / AVA 1 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
r20135 BO: AVA 1 input negative SN / AVA 1 input neg SN
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20136 AVA 1 run-time group / AVA 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
