List of Parameters
Parameters
1-219
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the identified stator resistance.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
Description: Displays the identified rotor time constant.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
Description: Displays the identified total leakage inductance.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
Description: Displays the nominal stator inductance identified.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
Description: Displays the nominal stator inductance identified for the 1st point of the saturation characteristic.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
Description: Displays the nominal stator inductance identified for the 2nd point of the saturation characteristic.
Index: [0] = Phase U
[1] = Phase V
[2] = Phase W
r1912[0...2] Identified stator resistance / R_stator ident
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [Ohm] Scaling: - Data set: -
r1913[0...2] Identified rotor time constant / T_rotor ident
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [ms] Scaling: - Data set: -
r1914[0...2] Identified total leakage inductance / L_total_leak ident
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [mH] Scaling: - Data set: -
r1915[0...2] Identified nominal stator inductance / L_stator ident
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [mH] Scaling: - Data set: -
r1916[0...2] Identified stator inductance 1 / L_stator 1 ident
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [mH] Scaling: - Data set: -
r1917[0...2] Identified stator inductance 2 / L_stator 2 ident
Access level: 4 Calculated: - Data type: FloatingPoint32
Unit: [mH] Scaling: - Data set: -
