Siemens CU230P-2 DP - p1513[0...n] CI: Supplementary torque 2; M_suppl 2; p1514[0...n] Supplementary torque 2 scaling; M_suppl 2 scal; r1515 Supplementary torque total; M_suppl total; r1516 CO: Supplementary torque and acceleration torque; M_suppl + M_accel

List of Parameters
Parameters
1-191
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the signal source for supplementary torque 2.
Description: Sets the scaling for supplementary torque 2.
Description: Displays the total supplementary torque.
The displayed value is the total of supplementary torque values 1 and 2 (p1511, p1512, p1513, p1514).
Description: Displays the total supplementary torque and the accelerating torque.
The displayed value is the total of the smoothed supplementary torque and the accelerating torque (p1516 =
p1518[1] + r1515).
Description: Sets the smoothing time constant of the accelerating torque.
Note: The acceleration pre-control is inhibited if the smoothing is set to the maximum value.
Description: Displays the accelerating torque for pre-control of the speed controller.
Index: [0] = Unsmoothed
[1] = Smoothed
Dependency: Refer to: p0341, p0342, p1496
p1513[0...n] CI: Supplementary torque 2 / M_suppl 2
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: p2003 Data set: CDS, p0170
Min Max Factory setting
- - 0
p1514[0...n] Supplementary torque 2 scaling / M_suppl 2 scal
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: DDS, p0180
Min Max Factory setting
-2000.0 [%] 2000.0 [%] 100.0 [%]
r1515 Supplementary torque total / M_suppl total
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [Nm] Scaling: p2003 Data set: -
r1516 CO: Supplementary torque and acceleration torque / M_suppl + M_accel
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [Nm] Scaling: p2003 Data set: -
p1517[0...n] Accelerating torque smoothing time constant / M_accel T_smooth
Access level: 4 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.00 [ms] 100.00 [ms] 4.00 [ms]
r1518[0...1] CO: Accelerating torque / M_accel
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [Nm] Scaling: p2003 Data set: -
