Siemens CU230P-2 DP - p20196 RSR 1 run-time group; RSR 1 RTG; p20197 RSR 1 run sequence; RSR 1 RunSeq; p20198[0...3] BI: DFR 0 inputs; DFR 0 inputs; r20199 BO: DFR 0 output Q; DFR 0 output Q

Parameters
List of Parameters
1-376
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run-time group in which instance RSR 1 of the RS flipflop is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance RSR 1 within the run-time group set in p20196.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for trigger input I, D input D, set input S, and reset input R of instance DFR 0 of the D flipflop.
Index: [0] = Trigger input I
[1] = D input D
[2] = Set S
[3] = Reset R
Description: Display parameter for output Q of instance DFR 0 of the D flipflop.
Description: Display parameter for the inverted output QN of instance DFR 0 of the D flipflop.
p20196 RSR 1 run-time group / RSR 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
1 9999 9999
p20197 RSR 1 run sequence / RSR 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 7999 530
p20198[0...3] BI: DFR 0 inputs / DFR 0 inputs
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
r20199 BO: DFR 0 output Q / DFR 0 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r20200 BO: DFR 0 inverted output QN / DFR 0 inv outp QN
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
