Siemens CU230P-2 DP - r1732[0...1] CO: Direct-axis voltage setpoint; Direct V set; r1733[0...1] CO: Quadrature-axis voltage setpoint; Quad V set; p1740[0...n] Gain resonance damping for encoderless closed loop control; Gain res_damp; p1745[0...n] Motor model error threshold stall detection; MotMod ThreshStall

Parameters
List of Parameters
1-202
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the direct-axis voltage setpoint Ud.
Index: [0] = Unsmoothed
[1] = Smoothed with p0045
Description: Displays the quadrature-axis component of voltage setpoint Uq.
Index: [0] = Unsmoothed
[1] = Smoothed with p0045
Description: Defines the gain of the controller for resonance damping for operation with encoderless vector control in the range
that current is impressed.
Description: Sets the fault threshold in order to detect a motor that has stalled.
If the error signal (r1746) exceeds the parameterized error threshold, then bit 12 in status word p1408 is set.
Dependency: If a stalled drive is detected (p1408.12 set), fault F07902 is output after the delay time set in p2178.
Refer to: p2178
Note: Monitoring is only effective in the low-speed range (below p1755 * (100% - p1756)).
Description: Signal to initiate stall detection
Note: The signal is not calculated while magnetizing and only in the low speed range (below p1755 * (100 % - p1756)).
r1732[0...1] CO: Direct-axis voltage setpoint / Direct V set
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [Vrms] Scaling: p2001 Data set: -
r1733[0...1] CO: Quadrature-axis voltage setpoint / Quad V set
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [Vrms] Scaling: p2001 Data set: -
p1740[0...n] Gain resonance damping for encoderless closed loop control / Gain res_damp
Access level: 3 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.000 10.000 0.025
p1745[0...n] Motor model error threshold stall detection / MotMod ThreshStall
Access level: 3 Calculated: p0340 = 1,3 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.0 [%] 1000.0 [%] 5.0 [%]
r1746 Motor model error signal stall detection / MotMod sig stall
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: - Data set: -
