List of Parameters
Parameters
1-261
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the DC link voltage threshold value for the messages:
"Vdc_act <= Vdc_threshold p2172" (BO: r2197.9)
"Vdc_act > Vdc_threshold p2172" (BO: r2197.10)
Dependency: Refer to: p2173
Description: Delay time for the comparison of the DC link voltage r0070 with the threshold value p2172.
Dependency: Refer to: p2172
Description: Sets the torque threshold value for the messages:
"Torque setpoint < torque threshold value 1 and n_set reached" (BO: r2198.9)
"Torque setpoint < torque threshold value 1" (BO: r2198.10)
"Torque setpoint > torque threshold value 1" (BO: r2198.13)
Dependency: Refer to: p2195, r2198
Description: Sets the speed threshold for the message "Motor locked" (BO: r2198.6).
Dependency: Refer to: p0500, p2177, r2198
Note: The following applies for encoderless vector control:
At low speeds in open-loop speed controlled operation (see p1755, p1756), a locked motor cannot be detected.
Description: Delay time for the comparison of the absolute torque actual value r0080 with the threshold value p2174.
Dependency: Refer to: p2174
p2172[0...n] DC link voltage, threshold value / Vdc thresh val
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: p2001 Data set: DDS, p0180
Min Max Factory setting
0 [V] 2000 [V] 800 [V]
p2173[0...n] Delay time Vdc comparison / t_del Vdc
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 [ms] 10000 [ms] 10 [ms]
p2174[0...n] Torque threshold value 1 / M_thresh val 1
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.00 [Nm] 20000000.00 [Nm] 5.13 [Nm]
p2175[0...n] Motor locked speed threshold / Mot lock n_thresh
Access level: 3 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 120.00 [rpm]
p2176[0...n] Delay time for the torque threshold value / t_del_M_thresh
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 [ms] 10000 [ms] 200 [ms]
