Siemens CU230P-2 DP - r11172 CO: Free tec_ctrl 1 actual value after limiter; Ftec1 act v af lim; r11173 CO: Free tec_ctrl 1 system deviation; Ftec1 sys dev; p11174 Free tec_ctrl 1 differentiation time constant; Ftec1 D comp T; p11180 Free tec_ctrl 1 proportional gain; Ftec1 Kp

Parameters
List of Parameters
1-342
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Display and connector output for the actual value after the limiter of the free technology controller 1.
Description: Display and connector output for the system deviation of the free technology controller 1.
Description: Sets the time constant for the differentiation (D component) of the free technology controller 1.
Note: Value = 0: Differentiation is deactivated.
Description: Sets the proportional gain (P component) of the free technology controller 1.
Note: Value = 0: The proportional gain is deactivated.
Description: Sets the integral time (I component, integrating time constant) of the free technology controller 1.
Note: Value = 0: The integral time is disabled.
If the parameter is set to zero during operation, the I component retains its most recent value.
Description: Sets the maximum limit of the free technology controller 1.
Dependency: Refer to: p11192
Note: The maximum limit must always be greater than the minimum limit (p11191 > p11192).
Description: Sets the minimum limit of the free technology controller 1.
Dependency: Refer to: p11191
Note: The maximum limit must always be greater than the minimum limit (p11191 > p11192).
r11172 CO: Free tec_ctrl 1 actual value after limiter / Ftec1 act v af lim
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
r11173 CO: Free tec_ctrl 1 system deviation / Ftec1 sys dev
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [%] Scaling: PERCENT Data set: -
p11174 Free tec_ctrl 1 differentiation time constant / Ftec1 D comp T
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [s] 60.000 [s] 0.000 [s]
p11180 Free tec_ctrl 1 proportional gain / Ftec1 Kp
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 1000.000 1.000
p11185 Free tec_ctrl 1 integral time / Ftec1 Tn
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.000 [s] 10000.000 [s] 30.000 [s]
p11191 CO: Free tec_ctrl 1 limit maximum / Ftec1 lim max
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
-200.00 [%] 200.00 [%] 100.00 [%]
p11192 CO: Free tec_ctrl 1 limit minimum / Ftec1 lim min
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: PERCENT Data set: -
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
