List of Parameters
Parameters
1-211
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the actual converter switching frequency.
Index: [0] = Actual
[1] = Minimum value of the modulator
Note: The selected pulse frequency (p1800) may be reduced if the drive converter has an overload condition (p0290).
Description: Sets the modulator mode.
Value: 0: Automatic changeover SVM/FLB
2: Space vector modulation (SVM)
3: SVM without overcontrol
4: SVM/FLB without overcontrol
10: SVM/FLB with modulation depth reduction
Dependency: If a sine-wave filter is parameterized as output filter (p0230 = 3, 4), then only space vector modulation without over-
control can be selected as modulation type (p1802 = 3).
Refer to: p0230
Note: When modulation modes are enabled that could lead to overmodulation (p1802 = 0, 2, 10), the modulation depth
must be limited using p1803 (pre-assignment, p1803 = 98%). The higher the overmodulation, the greater the cur-
rent ripple and torque ripple. With p1802 = 10, the modulation depth limit is automatically reduced to 100% in the
critical output frequency range (over approx. 57 Hz).
When changing p1802[x], the values for all of the other existing indices are also changed.
Description: Sets the modulator mode.
Value: 0: Automatic changeover SVM/FLB
2: Space vector modulation (SVM)
3: SVM without overcontrol
4: SVM/FLB without overcontrol
Dependency: If a sine-wave filter is parameterized as output filter (p0230 = 3, 4), then only space vector modulation without over-
control can be selected as modulation type (p1802 = 3).
Refer to: p0230
Note: When modulation modes are enabled that could lead to overmodulation (p1802 = 0, 2, 10), the modulation depth
must be limited using p1803 (pre-assignment, p1803 = 98%). The higher the overmodulation, the greater the cur-
rent ripple and torque ripple. With p1802 = 10, the modulation depth limit is automatically reduced to 100% in the
critical output frequency range (over approx. 57 Hz).
When changing p1802[x], the values for all of the other existing indices are also changed.
r1801[0...1] CO: Pulse frequency / Pulse frequency
Access level: 2 Calculated: - Data type: FloatingPoint32
Unit: [kHz] Scaling: p2000 Data set: -
p1802[0...n] Modulator mode / Modulator mode
PM230 Access level: 3 Calculated: p0340 = 1,3,5 Data type: Integer16
Can be changed: T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 10 10
p1802[0...n] Modulator mode / Modulator mode
PM230
PM250, PM260
Access level: 3 Calculated: p0340 = 1,3,5 Data type: Integer16
Can be changed: T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 4 4
